Product details
1. Wide voltage: AC90V-235V 50-60Hz
2. Wide voltage driving power supply: 600W
3. Imported light source system: 371W (Osram)
4. Color temperature; 8000K
5. Color system: Color palette: 14+rainbow effect+atomization function
6. Pattern system: Pattern disk: 17 fixed patterns+1 white light
7. Focusing system: electronic focusing
8. Atomization; Equipped with atomization function and capable of achieving soft lighting effect
9. Strobe; Dual motor independent strobe effect, 0.5-20 times/second, adjustable speed
10. Motor: The XY axis uses a three-phase motor, which ensures high speed stability and accurate positioning angle of the lamp!
11. Dimming curve: 0% -100% linear dimming, smooth without flicker
12. Beam angle: 2-5°
13. Dual channel: 16 channel or 20 channel
14. Lens diameter: 160mm
15. Waterproof grade: IP55
16. Control mode 1: DMX 512， Self driving, master-slave self driving, RDM function, can use large-scale control
Remote setting of address code for controller control
17. Prism system: 8 prisms and (8+16) prisms (prisms can be configured according to customer requirements).
18. Display screen: LCD display screen, adaptable to different installation positions, rotatable 180 °
19. Horizontal and Vertical: Using high-precision three-phase motors, accurate positioning, smooth operation, and automatic correction of positioning
20. Horizontal: 540 ° rotation, resolution 8/16 bit, with fine tuning
21. Vertical: 270 ° rotation, resolution 8/16 bit, with fine tuning.
22. Heat dissipation system: Using physical fan heating method and air convection system method, software is used to analyze and calculate the heat flow of the lamp, quickly solving the internal heat of the body, extending the light source decay time, ensuring the service life of the light bulb, and designing a low-noise heat dissipation system with excellent fan driving performance and extremely low noise.
23. Installation method: upright/upside down
24. Lamp body size: 36 * 31 * 60cm Net weight: 20KG Gross weight: 24KG
Craftsmanship masterpiece: High end appearance, huge energy, thick light column waterproof beam lamp achieves high standard performance in terms of optics, structure, appearance, etc. It adopts the most advanced technology high brightness light source, optical technology, and rigorous industrial design to ensure the perfect presentation of lighting design.
